Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3

Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3
Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3
$806.99 ea
NEWARRIVING SOONEstimated Ship Date 01/07/2025 (If Ordered Today)100 Available from HOLLEY PERFORMANCE PRODUCTS as of 12/22/2024
Model: 3316007
Select a Vehicle or refer to the Vehicle Fitment Tab below to verify that this part fits your vehicle.
STANDARD
DELIVERY
STORE PICKUP
[More Info]
Holley engineering has taken their LS Swap oil pans to the next level! The 302-3 design has even more sump clearance, includes two 1/2-inch NPT oil return bosses, and can clear a 4.00-inch stroke crankshaft. Just like the 302-2, the new designed 302-3 will fit the 1955-1987 GM Muscle Cars and Trucks that need a little more clearance in the front of the oil pan. However, the new design will also fit the Ford Fox body Factory K-member and was designed to clear the Fox Body rack and pinion too. It's a win-win for more LS conversions.
Features:
  • Designed for LS engine retrofit installations in GM muscle/classic car and truck chassis requiring more oil pan to chassis clearance around the front half of the oil pan
  • Profile of the sump has been revised to provide extra chassis and steering rack clearance
  • Perfect for: 1967-1969 Camaro/Firebird, 1968-1974 Nova/Apollo/Ventura/Omega, 1982-1992 F-body, 1978-1987 G-body, and 1964-1972 A-body applications. Also 1979-2004 Mustang and 1979-1986 Capri Fox bodies
  • NOTE – Oil pan #302-3 will clear a 4.00-inch stroke crankshaft.
  • Includes two 1/2-inch NPT oil return ports to provide a convenient oil return for turbochargers. (one port on each side)
  • Can be used with Earls oil cooler adaptor LS0012ERL and LS0013ERL, or Earls oil cooler block off plate LS0020ERL with 1/8-inch NPT port
  • Provides OE Style fitment - OE oil filter mounting, OE oil cooler port provision, OE engine NVH suppression, OE flange gasket and sealing, proper structural rigidity and OE bell-housing attachments
  • Traditional high-quality cast aluminum appearance with clean exterior styling
  • Provides maximum clearance for vehicles where the steering linkage is behind the engine cross member
  • Complete kit includes sump baffle, OE style pick-up tube, sump plug, oil filter stud, oil passage cover, etc.
Maximum crankshaft stroke = 4.00" Sump Oil Capacity - 5.6 Quarts Total Oil Capacity with stock oil filter - 6.1 Quarts Oil Filter (AC Delco® PF48 or PF48E, Mobile M1-113, Wix 57060, K&N HP-1017, or equivalent) Requires use of Holley 302-15 Dipstick and Tube Kit or LS3 dipstick (GM P/N 12669528) and tube (GM P/N 12625031) *Engine location may need to be adjusted (up / down or fore / aft) for cross member or steering linkage clearance depending on the vehicle, steering configuration and chassis type. ATTENTION! 302-3 is designed to use a GM "F-body" windage tray, GM P/N 12558253. A modification to the windage tray is required to provide clearance to the pick-up tube. A full-length windage tray may be used if the front quarter of the tray is removed. See the instruction sheets showing the windage tray modifications and overall length required. ATTENTION! Additional Parts Needed (Oil Pan Gasket 6665G or GM® 12612350, High Quality RTV sealer, Oil Filter -AC Delco® PF48 or equivalent)
Installation Notes:
Maximum crankshaft stroke = 4.00" Sump Oil Capacity - 5.6 Quarts Total Oil Capacity with stock oil filter - 6.1 Quarts Oil Filter (AC Delco® PF48 or PF48E, Mobile M1-113, Wix 57060, K&N HP-1017, or equivalent) Requires use of Holley 302-15 Dipstick and Tube Kit or LS3 dipstick (GM P/N 12669528) and tube (GM P/N 12625031) *Engine location may need to be adjusted (up / down or fore / aft) for cross member or steering linkage clearance depending on the vehicle, steering configuration and chassis type. ATTENTION! 302-3 is designed to use a GM "F-body" windage tray, GM P/N 12558253. A modification to the windage tray is required to provide clearance to the pick-up tube. A full-length windage tray may be used if the front quarter of the tray is removed. See the instruction sheets showing the windage tray modifications and overall length required. ATTENTION! Additional Parts Needed (Oil Pan Gasket 6665G or GM® 12612350, High Quality RTV sealer, Oil Filter -AC Delco® PF48 or equivalent)
About Holley Performance Products

Holley has been the undisputed leader in fuel systems for over 100 years. Holley carburetors powered every Monster Energy NASCAR Cup team and nearly every NHRA Pro-Stock champion for four decades. Now, Holley EFI products power these cars and are dominating the performance world. Holley products for GM's popular LS engine are dominating the LS scene as well. Holley's products also include performance fuel pumps, intake manifolds and engine dress-up products for street performance, race and marine applications. As a single solution or partnered with products from other Holley companies we can give you the edge you need over the competition!

Downloads:

Download Name File Size
199r11351.pdf657.97KB

Videos:

Vehicle Fitment:

The Vehicle Fitment Guide is to be used as a general reference. The data has been provided by our suppliers and manufacturers and may contain errors or incorrect data. Always refer to a professional to verify correct fitment for your vehicle.
Make Model Submodel Years Fitment Notes
Chevrolet Blazer Base 1973 - 1974 LS Swap; 2-Wheel Drive
Chevrolet Blazer Custom Deluxe 1987 LS Swap; 2-Wheel Drive
Chevrolet Blazer Scottsdale 1988 - 1991 LS Swap; 2-Wheel Drive
Chevrolet Blazer Silverado 1987 - 1991 LS Swap; 2-Wheel Drive
Chevrolet C10 Pickup Base 1963 - 1972 LS Swap
Chevrolet C10 Pickup 1973 - 1974 LS Swap; LS-SWAP
Chevrolet C10 Suburban Base 1973 - 1974 LS Swap
Chevrolet C10 Suburban Custom Deluxe 1975 - 1980 LS Swap
Chevrolet C10 Suburban Custom 1981 - 1986 LS Swap
Chevrolet C10 Suburban Deluxe 1981 LS Swap
Chevrolet C10 Suburban Scottsdale 1975 - 1986 LS Swap
Chevrolet C10 Suburban Silverado 1975 - 1986 LS Swap
Chevrolet C10 Suburban 1973 - 1986 LS Swap; LS-SWAP
Chevrolet C10 Big Ten 1978 - 1980 LS Swap
Chevrolet C10 Cheyenne 1975 - 1981 LS Swap
Chevrolet C10 Custom Deluxe 1975 - 1980 LS Swap
Chevrolet C10 Custom 1975 - 1986 LS Swap
Chevrolet C10 Deluxe 1981 LS Swap
Chevrolet C10 Scottsdale 1975 - 1986 LS Swap
Chevrolet C10 Silverado 1975 - 1986 LS Swap
Chevrolet C10 1975 - 1986 LS Swap; LS-SWAP
Chevrolet C1500 454 SS 1990 - 1993 LS Swap; With Holley Swap Mounts & Headers
Chevrolet C1500 Base 1989 - 1998 LS Swap; With Holley Swap Mounts & Headers
Chevrolet C1500 Cheyenne 1988 - 1998 LS Swap; With Holley Swap Mounts & Headers
Chevrolet C1500 Scottsdale 1988 - 1992 LS Swap; With Holley Swap Mounts & Headers
Chevrolet C1500 Silverado 1988 - 1998 LS Swap; With Holley Swap Mounts & Headers
Chevrolet C1500 WT 1990 - 1998 LS Swap; With Holley Swap Mounts & Headers
Chevrolet C15 Base 1987 LS Swap
Chevrolet C15 Cheyenne 1982 - 1986 LS Swap
Chevrolet C15 Custom 1982 - 1986 LS Swap
Chevrolet C15 Sport 1984 LS Swap
Chevrolet C15 1987 LS Swap; LS-SWAP
Chevrolet C20 Pickup Base 1973 - 1974 LS Swap
Chevrolet C20 Pickup 1973 - 1974 LS Swap; LS-SWAP
Chevrolet C20 Suburban Base 1973 - 1974 LS Swap
Chevrolet C20 Suburban Custom Deluxe 1975 - 1980 LS Swap
Chevrolet C20 Suburban Custom 1981 - 1986 LS Swap
Chevrolet C20 Suburban Deluxe 1981 LS Swap
Chevrolet C20 Suburban Scottsdale 1975 - 1986 LS Swap
Chevrolet C20 Suburban Silverado 1975 - 1986 LS Swap
Chevrolet C20 Suburban 1973 - 1986 LS Swap; LS-SWAP
Chevrolet C20 Base 1986 - 1987 LS Swap
Chevrolet C20 Cheyenne 1975 - 1987 LS Swap
Chevrolet C20 Custom Deluxe 1975 - 1980 LS Swap
Chevrolet C20 Custom 1981 - 1986 LS Swap
Chevrolet C20 Deluxe 1981 LS Swap
Chevrolet C20 Scottsdale 1975 - 1986 LS Swap
Chevrolet C20 Silverado 1975 - 1986 LS Swap
Chevrolet C20 1975 - 1987 LS Swap; LS-SWAP
Chevrolet El Camino Base 1964 - 1987 LS Swap
Chevrolet El Camino Conquista 1978 - 1986 LS Swap
Chevrolet El Camino Custom 1968 - 1972 LS Swap
Chevrolet El Camino Royal Knight 1979 - 1981 LS Swap
Chevrolet El Camino SS 1968 - 1987 LS Swap
Chevrolet K10 Pickup Base 1973 - 1974 LS Swap
Chevrolet K10 Cheyenne 1975 - 1981 LS Swap
Chevrolet K10 Custom Deluxe 1975 - 1980 LS Swap
Chevrolet K10 Custom 1981 - 1986 LS Swap
Chevrolet K10 Deluxe 1981 LS Swap
Chevrolet K10 Scottsdale 1975 - 1986 LS Swap
Chevrolet K10 Silverado 1975 - 1986 LS Swap
Chevrolet K1500 Base 1994 - 1997 LS Swap; With Holley Swap Mounts & Headers
Chevrolet K1500 Cheyenne 1988 - 1998 LS Swap; With Holley Swap Mounts & Headers
Chevrolet K1500 Scottsdale 1988 - 1992 LS Swap; With Holley Swap Mounts & Headers
Chevrolet K1500 Silverado 1988 - 1998 LS Swap; With Holley Swap Mounts & Headers
Chevrolet K1500 Sport 1991 LS Swap; With Holley Swap Mounts & Headers
Chevrolet K1500 WT 1990 - 1998 LS Swap; With Holley Swap Mounts & Headers
Chevrolet K5 Blazer Base 1976 LS Swap; 2-Wheel Drive
Chevrolet K5 Blazer Cheyenne 1975 - 1980 LS Swap; 2-Wheel Drive
Chevrolet K5 Blazer Custom Deluxe 1975 - 1980 LS Swap; 2-Wheel Drive
Chevrolet K5 Blazer Custom 1981 - 1986 LS Swap; 2-Wheel Drive
Chevrolet K5 Blazer Deluxe 1981 LS Swap; 2-Wheel Drive
Chevrolet K5 Blazer Scottsdale 1984 LS Swap; 2-Wheel Drive
Chevrolet K5 Blazer Silverado 1978 - 1986 LS Swap; 2-Wheel Drive
Chevrolet R10 Suburban Custom Deluxe 1987 LS Swap
Chevrolet R10 Suburban Scottsdale 1987 LS Swap
Chevrolet R10 Suburban Silverado 1987 LS Swap
Chevrolet R10 Suburban 1987 LS Swap; LS-SWAP
Chevrolet R10 Custom Deluxe 1987 LS Swap
Chevrolet R10 Scottsdale 1987 LS Swap
Chevrolet R10 Silverado 1987 LS Swap
Chevrolet R20 Suburban Custom Deluxe 1987 LS Swap
Chevrolet R20 Suburban Scottsdale 1987 LS Swap
Chevrolet R20 Suburban Silverado 1987 LS Swap
Chevrolet R20 Suburban 1987 LS Swap; LS-SWAP
Chevrolet R20 Custom Deluxe 1987 LS Swap
Chevrolet R20 Scottsdale 1987 LS Swap
Chevrolet R20 Silverado 1987 LS Swap
Chevrolet V10 Custom Deluxe 1987 LS Swap
Chevrolet V10 Scottsdale 1987 LS Swap
Chevrolet V10 Silverado 1987 LS Swap
GMC C15 Suburban Base 1975 - 1978 LS Swap
GMC C15 Suburban High Sierra 1975 - 1978 LS Swap
GMC C15 Suburban Sierra Classic 1975 - 1978 LS Swap
GMC C15 Suburban Sierra Grande 1975 - 1978 LS Swap
GMC C15/C1500 Pickup Base 1967 - 1972 LS Swap
GMC C15/C1500 Suburban Base 1973 - 1974 LS Swap
GMC C1500 Suburban Base 1979 - 1986 LS Swap
GMC C1500 Suburban High Sierra 1979 - 1986 LS Swap
GMC C1500 Suburban Sierra Classic 1979 - 1986 LS Swap
GMC C1500 Suburban Sierra Grande 1979 - 1982 LS Swap
GMC C1500 Sierra GT 1997 LS Swap; With Holley Swap Mounts & Headers
GMC C1500 Sierra SLE 1988 - 1998 LS Swap; With Holley Swap Mounts & Headers
GMC C1500 Sierra SLT 1994 - 1998 LS Swap; With Holley Swap Mounts & Headers
GMC C1500 Sierra SLX 1988 - 1993 LS Swap; With Holley Swap Mounts & Headers
GMC C1500 Sierra SL 1994 - 1998 LS Swap; With Holley Swap Mounts & Headers
GMC C1500 Sierra Special 1994 - 1998 LS Swap; With Holley Swap Mounts & Headers
GMC C1500 Sierra 1988 - 1993 LS Swap; With Holley Swap Mounts & Headers
GMC C15 Base 1975 - 1978 LS Swap
GMC C15 Heavy Half 1977 - 1978 LS Swap
GMC C15 High Sierra 1975 - 1978 LS Swap
GMC C15 Indy Hauler 1977 LS Swap
GMC C15 Sierra Classic 1975 - 1978 LS Swap
GMC C15 Sierra Grande 1975 - 1978 LS Swap
GMC C15 Street Coupe 1978 LS Swap
GMC C25 Suburban Base 1975 - 1978 LS Swap
GMC C25 Suburban High Sierra 1975 - 1978 LS Swap
GMC C25 Suburban Sierra Classic 1975 - 1978 LS Swap
GMC C25 Suburban Sierra Grande 1975 - 1978 LS Swap
GMC C25/C2500 Pickup Base 1973 - 1974 LS Swap
GMC C25/C2500 Suburban Base 1973 - 1974 LS Swap
GMC C2500 Base 1979 - 1986 LS Swap
GMC C2500 High Sierra 1979 - 1986 LS Swap
GMC C2500 Sierra Classic 1979 - 1986 LS Swap
GMC C2500 Sierra Grande 1979 - 1982 LS Swap
GMC C25 Base 1975 - 1978 LS Swap
GMC C25 High Sierra 1975 - 1978 LS Swap
GMC C25 Sierra Classic 1975 - 1978 LS Swap
GMC C25 Sierra Grande 1975 - 1978 LS Swap
GMC Caballero Amarillo 1981 - 1986 LS Swap
GMC Caballero Base 1978 - 1987 LS Swap
GMC Caballero Conquista 1981 LS Swap
GMC Caballero Diablo 1978 - 1987 LS Swap
GMC Caballero Laredo 1978 - 1980 LS Swap
GMC Caballero Royal Knight 1981 LS Swap
GMC Jimmy Base 1973 - 1991 LS Swap; 2-Wheel Drive
GMC Jimmy High Sierra 1975 - 1985 LS Swap; 2-Wheel Drive
GMC Jimmy Sierra Classic 1975 - 1990 LS Swap; 2-Wheel Drive
GMC Jimmy Sierra Grande 1975 - 1982 LS Swap; 2-Wheel Drive
GMC Jimmy Silverado 1986 LS Swap; 2-Wheel Drive
GMC Jimmy Street Coupe 1978 - 1982 LS Swap; 2-Wheel Drive
GMC K15/K1500 Pickup Base 1973 - 1974 LS Swap
GMC K1500 Sierra SLE 1988 - 1998 LS Swap; With Holley Swap Mounts & Headers
GMC K1500 Sierra SLS 1995 LS Swap; With Holley Swap Mounts & Headers
GMC K1500 Sierra SLT 1994 - 1998 LS Swap; With Holley Swap Mounts & Headers
GMC K1500 Sierra SLX 1988 - 1993 LS Swap; With Holley Swap Mounts & Headers
GMC K1500 Sierra SL 1994 - 1998 LS Swap; With Holley Swap Mounts & Headers
GMC K1500 Sierra Special 1994 - 1998 LS Swap; With Holley Swap Mounts & Headers
GMC K1500 Sierra Sport 1993 LS Swap; With Holley Swap Mounts & Headers
GMC K1500 Sierra 1988 - 1993 LS Swap; With Holley Swap Mounts & Headers
GMC K15 Base 1975 - 1978 LS Swap
GMC K15 High Sierra 1975 - 1978 LS Swap
GMC K15 Indy Hauler 1977 LS Swap
GMC K15 Sierra Classic 1975 - 1978 LS Swap
GMC K15 Sierra Grande 1975 - 1978 LS Swap
GMC R1500 Suburban Base 1987 LS Swap
GMC R1500 Suburban High Sierra 1987 LS Swap
GMC R1500 Suburban Sierra Classic 1987 LS Swap
GMC R1500 Base 1987 LS Swap
GMC R1500 High Sierra 1987 LS Swap
GMC R1500 Sierra Classic 1987 LS Swap
GMC R2500 Suburban Base 1987 LS Swap
GMC R2500 Suburban High Sierra 1987 LS Swap
GMC R2500 Suburban Sierra Classic 1987 LS Swap
GMC R2500 Base 1987 LS Swap
GMC R2500 High Sierra 1987 LS Swap
GMC R2500 Sierra Classic 1987 LS Swap
GMC Sprint Base 1971 - 1972 LS Swap
GMC Sprint Custom 1972 LS Swap

Specifications:

Application GM LS Engines
Choose Your Part Oil Pan Kit
Emission Code 6
Finish Natural Cast
Material Aluminum
Maximum Stroke 4.00"
Oil Pan Capacity 5.6 Quarts
Oil Pan Type Cast
Oil Return Size 1/2" NPT
Part Type Engine Oil Pan
Product Type Oil Pan Kit
Sump Location Rear
Turbo Oil Drainback Yes
Warranty Limited 90 Day
Windage Tray Included No

Reviews:

Write a Review
* Your Name:
* Email (This will not be displayed)
* Rating:
Comments:

Ask a question about

Holley GM LS Swap Oil Pan, Additional Front Clearance 302-3:
Reason for Inquiry:

Related Products

Chevy Chrome Oil Pan, Big Block, 1949-1954
Chevy Chrome Oil Pan, Big Block, 1949-1954
Model: 3018983
Condition: NEW
$109.99 ea
Scott Drake 1964-1973 Ford Mustang 64-73 Transmission Pan (C4, 1" Deeper, Natural Gray) C5ZZ-7A194-SD
Scott Drake 1964-1973 Ford Mustang 64-73 Transmission Pan (C4, 1" Deeper, Natural Gray) C5ZZ-7A194-SD
Model: 3016719
Condition: NEW
$48.99 ea
Chrome Plated Engine Oil Pan, Small Block, 283-350, 1986-2002
Chrome Plated Engine Oil Pan, Small Block, 283-350, 1986-2002
Model: 1026328
Condition: NEW
$170.99 ea
Oil Pan - Chrome - 351 Cleveland V8
Oil Pan - Chrome - 351 Cleveland V8
Model: 3011328
Condition: NEW
$134.99 ea
Oil Pan - Bare Steel
Oil Pan - Bare Steel
Model: 3011320
Condition: NEW
$137.99 ea

Frequently bought together

OER 1968-90 GM Chrome Ribbed Diecast Door Lock Knobs K546
OER 1968-90 GM Chrome Ribbed Diecast Door Lock Knobs K546
Model: 3446653
Condition: NEW
$22.99 pr
Hays Street 650 Clutch Kit, GM 92-1002
Hays Street 650 Clutch Kit, GM 92-1002
Model: 3316520
Condition: NEW
$1,376.99 ea
Hooker Motor Mount Bracket 71221004HKR
Hooker Motor Mount Bracket 71221004HKR
Model: 3316018
Condition: NEW
$41.99 ea
Holley EFI Fuel System Kit 526-2
Holley EFI Fuel System Kit 526-2
Model: 3316008
Condition: NEW
$1,703.35 ea
Mr. Gasket Ultra-Seal Header Gaskets 5966
Mr. Gasket Ultra-Seal Header Gaskets 5966
Model: 3316017
Condition: NEW
$67.99 ea
